Column speakers

PA column speakers, in extruded aluminium cabinets ETS-210TW/WS

Slim Design, Weatherproof Version

PA column speakers, in extruded aluminium cabinets.

Weatherproof and hose-proof
100 V line technique
2-way version (with additional integrated tweeters for a clearly improved sound)
Connection cable with 5-step power taps
2 x M6 threaded bushing
Aluminium front grille
Supplied with mounting brackets

Specifications:

Frequency range: 170-20,000 Hz
Number of speakers: 2+1
Power rating: 10/5/2.5/1.25/0.63 W_RMS
SPL (1 W/1 m): 86 dB
Admiss. ambient temp.: -20 °C to +50 °C
Dimensions: 80x280x70 mm
Weight: 1 kg

Price per unit (Order No. mo-162940) EUR 177,90 excl. VAT: € 149.50 / $ 173.42

PA column speakers ETS-215TW/WS

PA column speakers, in extruded aluminium cabinets, with top and bottom plates of aluminium.

100 V line technique
2-way version (with additional integrated tweeters for a clearly improved sound)
Integrated crossover network
5-step power selector switch
2 x M6 threaded bushing
Metal front grille
Supplied with mounting brackets
Connection via cable, 2 cores

ETS-230TW/WS with 4 tweeters

ETS-215TW/WS with 2 tweeters

Specifications:

Frequency range: 250-20,000 Hz
Number of speakers: 4+2
Power rating: 12/6/3/1.5 W_RMS
SPL (1 W/1 m): 90 dB
Dimensions: 105x410x75 mm
Weight: 2.6 kg

Price per unit (Order No. mo-162100) EUR 131,70 excl. VAT: € 110.67 / $ 128.38

PA column speakers, in extruded aluminium cabinets ETS-220TW/WS

Slim Design, Weatherproof Version

PA column speakers, in extruded aluminium cabinets.

Weatherproof and hose-proof
100 V line technique
2-way version (with additional integrated tweeters for a clearly improved sound)
Connection cable with 5-step power taps
2 x M6 threaded bushing
Aluminium front grille
Supplied with mounting brackets

Specifications:

Frequency range: 150-20,000 Hz
Number of speakers: 4+2
Power rating: 20/15/10/5/2.5 W_RMS
SPL (1 W/1 m): 89 dB
Admiss. ambient temp.: -20 °C to +50 °C
Dimensions: 80x469x70 mm
Weight: 1.7 kg

Price per unit (Order No. mo-162950) - not available

PA column speakers ETS-230TW/WS

PA column speakers, in extruded aluminium cabinets, with top and bottom plates of aluminium.

100 V line technique
2-way version (with additional integrated tweeters for a clearly improved sound)
Integrated crossover network
5-step power selector switch
2 x M6 threaded bushing
Metal front grille
Supplied with mounting brackets
Connection via cable, 2 cores

ETS-230TW/WS with 4 tweeters ETS-215TW/WS with 2 tweeters

Specifications:

Frequency range: 200-20,000 Hz
Number of speakers: 8+4
Power rating: 20/10/5/2.5 W_RMS
SPL (1 W/1 m): 94 dB
Dimensions: 105x700x75 mm
Weight: 4.2 kg

Price per unit (Order No. mo-162110) EUR 182,30 excl. VAT: € 153.19 / $ 177.70

PA column speakers, in extruded aluminium cabinets ETS-240TW/WS

Slim Design, Weatherproof Version

PA column speakers, in extruded aluminium cabinets.

Weatherproof and hose-proof
100 V line technique
2-way version (with additional integrated tweeters for a clearly improved sound)
Connection cable with 5-step power taps
2 x M6 threaded bushing
Aluminium front grille
Supplied with mounting brackets

Specifications:

Frequency range: 150-20,000 Hz
Number of speakers: 8+4
Power rating: 40/30/20/10/5 W_RMS
SPL (1 W/1 m): 90 dB
Admiss. ambient temp.: -20 °C to +50 °C
Dimensions: 80x846x70 mm
Weight: 2.8 kg

Price per unit (Order No. mo-162960) - not available

High-end column speakers, (indoors), 100 V, ETS-340TW/WS

The new generation of column speakers from MONACOR:All the advantages of a column speaker (shape, directional characteristic and mounting) are now combined with an excellent sound quality and a particularly high level stability. With the 2-way ETS speakers in a wooden cabinet (BN: high-quality decorative wood design, WS: white decorative surface with wood pattern), most varying requirements can be met by these speaker systems, like a very good speech intelligibility and at the same time an optimised music reproduction of the full range.

High-end column speakers, (indoors), 100 V.

Column speakers in a wooden cabinet of compact size, coated with high-quality foils in decorative wood pattern (BN: natural brown, WS: white with structured wood pattern), 2½-way technology with tweeter (25 mm textile dome), clearly extended frequency range compared with standard full range column speakers. The sound is ideally matched to the reproduction of both music and vocals.

4 bass speakers, 2 bass-midrange speakers, 1 tweeter
Spring-loaded terminal with 3 power taps
2 x M8 threaded bushing
Supplied with mounting brackets
Metal front grille

PROSOUND 01/2008

"Unobtrusive design, good workmanship and technology ... really favourable price."

Specifications:

Frequency range: 100-19,000 Hz
Number of speakers: 6+1
Power rating: 40/20/10 W_RMS
SPL (1 W/1 m): 92 dB
Dimensions: 95x500x120 mm
Weight: 3.5 kg

Price per unit (Order No. mo-162250) EUR 252,00 excl. VAT: € 211.76 / $ 245.65

High-end column speakers, (indoors), 100 V, ETS-360TW/WS

High-end column speakers, (indoors), 100 V.

Column speakers in a wooden cabinet of compact size, coated with high-quality foils in decorative wood pattern (BN: natural brown, WS: white with structured wood pattern), 2½-way technology with tweeter (25 mm textile dome), clearly extended frequency range compared with standard full range column speakers. The ETS-360... speakers impress with an enormously dynamic and complete sound which is convincing due to a good speech intelligibility and a surprisingly great sound also at higher volume levels.

2 bass speakers, 4 bass-midrange speakers, 1 tweeter
Spring-loaded terminals with 3 power taps
2 x M8 threaded bushing
Supplied with mounting brackets
Metal front grille

PROSOUND 01/2008

"Can be integrated into almost any architectural style without any problems. These speaker systems can be operated somewhere for 20 years without being noticed."

Specifications:
